- Compact: Detector for scans in vertical and horizontal orientation - supporting graphical 3D measurements, acoustic magnetic field measurements and instant live images
- Measuring Depth: customers found objects to 21 m (69 ft) deep
- Use cases: treasure hunting, cavity detection
- Operating modes: Ground Scan, Live Sound (Magnetometer), Live Stream
- Detectable objects: treasure chests, cavities, tunnels
Fusion Professional Plus from OKM is a 3D scanner with a built-in inductive search coil. This multifunctional detector helps treasure hunters, archaeologists and engineers with 3D graphic measurements, acoustic magnetic field measurements and live footage.
How to use the Fusion Professional Plus 3D floor scanner?
The Advanced Professional Plus Edition can be used in portrait and landscape orientation and supports 3D ground scanning, live audio, and direct scanning playback modes:
OKM Fusion Professional Plus operating modes
3D Ground Survey
OKM Fusion Professional Plus 3D Ground Scanning
3D Ground Survey: 3D optical measurement for detailed computer analysis.
3D Ground Survey allows treasure hunters to view and analyze the structures and objects discovered in 3D scan images. These representations allow detectors to determine the location, size, and depth of potential treasures and hidden tunnels or burial chambers.
Live sound (live sound / magnetometer)
OKM Fusion Professional Plus Magnetometer (Live Audio)
Live sound: OKM Fusion Professional Plus magnetometer mode (live sound)
Live sound system (magnetometer) provides real-time detection of metallic objects near the surface. Treasure hunters and detectors use this mode to scan the scanning field before performing a more detailed 3D ground survey.
Direct Scan (Multi-Sensor)
OKM Fusion Professional Plus Live Scan with Horizontal Probe
Direct scanning with horizontal probe
Live Scan with Horizontal Probe provides instant visual feedback of the scanned area as a two-dimensional, color-coded representation.
Live scan (ultrasound)
OKM Fusion Professional Plus Live Scan with Vertical Probe
Direct scanning with vertical probe
Live Scan with Vertical Probe provides instant visual feedback of the scanned area in representations similar to ultrasound images.
View treasures quickly and easily with Live Scan
Direct Play mode is only available with Fusion Professional Plus. It can be performed with the fusion probe in a vertical or horizontal orientation. Depending on the orientation of the probe, the live images are displayed as a 2D representation (horizontal probe) or similar to an ultrasound representation (vertical probe).
The live vertical scanning mode creates ultrasound-like images.
Look at the ground using live ultrasound (vertical)
Scanning the target area with the probe in a vertical direction allows treasure hunters to search through galleries and narrow tunnels as well. In addition, in Live Scan mode, you can move the probe back and forth without following the scanning pattern. Abnormalities detected in the ground are immediately visualized in green colors and are reminiscent of ultrasound images.
Live landscape scan mode creates color-coded 2D images.
Scan large areas faster with multi-sensor direct scan mode (horizontal)
The Fusion Professional Plus probe is equipped with OKM's Multi-Sensor Technology. Thus, using the probe in a horizontal direction allows the two detectors to scan the target area faster. Visualizer 3D Studio instantly creates a color-coded 2D representation of objects and structures hidden during scanning.
Detect larger objects and structures with 3D ground scanning
3D Ground Scan Visualizes underground structures and objects in color-coded 3D representations. In addition, OKM detection technology allows detection of target objects at depths of up to 21 meters (69 feet).
High Resolution Scans with 3D Ground Scan (Vertical)
When using the detector in the vertical direction, you hold the probe in one hand and the tablet in the other. In addition, the built-in inductive search coil can be activated.
3D ground scanning with probe in vertical direction
3D ground scanning with probe in vertical direction
3D ground scanning with probe in landscape orientation
3D ground scanning with probe in landscape orientation
Multi-sensor scanning with 3D ground scanning (horizontal)
3D floor scanning with a horizontal probe is only available with Fusion Professional Plus.
When using the detector in the horizontal direction, the probe is attached to the telescopic rod and the rack is installed above the handle. In this way, the detector is able to control the detector very easily via the software on the tablet. In addition, the probe's horizontal orientation allows recording more values simultaneously thanks to the built-in multi-sensor technology.
Discover hidden treasures and burial chambers
Fusion Professional Plus users can locate buried treasures, artifacts, and other hidden objects before digging up. The data recorded from the 3D ground survey can be analyzed in detail using the detection software Visualizer 3D Studio: the detectors can not only identify anomalies, but also determine the size and depth of the detected underground structures.
OKM detection software with Ground Scan 3D
Professional fusion inductive search coil
Detect metal objects using the SRIS inductive search coil
The SRIS search file is used to locate sh
1x |
Control Unit |
1x |
Telescopic Rod |
1x |
Windows Notebook |
1x |
Software Visualizer 3D Studio Professional Edition |
1x |
Notebook mount |
1x |
Waterproof and shock resistant Protector case |
1x |
Bluetooth headphones |
1x |
Charger for control unit |
1x |
Travel adapter |
1x |
Quick Start Guide |
Control Unit
- Dimensions (H x W x D): 950 mm, 65 / 80 mm
- Weight: approx. 1 kg
- Processor / Main CPU: Cortex M3, 32 MHz
- Processor / Slave CPU: Cortex M0, 24 MHz
- Sample rate: 1024 values / second
- Measurement resolution: 16 bit
- Operating temperature: –10°C – 60°C
- Storage temperature: –20°C – 70°C
- Audio: Bluetooth Headphones
- Waterproof: No
- Sensor technology / Coil technology: SCMI-15-D / SRIS-18K
- Operating time: approx. 3 hours (delivered power supply, full charged battery, 25°C)
- Air humidity: 5% – 75%
- Protection Type: IP40
- Input (for Charger): 19 V DC / 3.16 A
Data Transmission
- Technology: Bluetooth 5.1
- Frequency: 2.402 – 2.480 GHz
- Maximum Transfer Rate: 1 Mbps
- Maximum Transmitting Power: +8 dBm
- Maximum Range: approx. 10 m
Computer Minimum Requirements
- Interface (data transmission): USB 2.0
- Free disk space: minimum 250 MB
- Working memory (RAM): 2 GB
- Display: 1920 x 1080
- Processor: 1.2 GHz
- Graphics card: 1 GB RAM, OpenGL 3.3
- Operating system: Windows 10
The technical data are average values. Minor deviations are possible during operation.
